15 | Technical data
Installer reference guide
228
EVLQ05+08CAV3 + EHYHBH05AF + EHYHBH/X08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1F – 2020.10
* = Optional
# = Field supply
Translation of text on wiring diagram
English Translation
(1) Main power connection (1) Main power connection
16 V DC detection (voltage supplied by
PCB)
16VDC detection (voltage supplied by
PCB)
For preferential kWh rate power supply For preferential kWh rate power supply
Indoor unit supplied from outdoor Indoor unit supplied from outdoor
Normal kWh rate power supply Normal kWh rate power supply
Only for normal power supply
(standard)
Only for normal power supply
(standard)
Only for preferential kWh rate power
supply (outdoor)
Only for preferential kWh rate power
supply (outdoor)
Outdoor unit Outdoor unit
Use normal kWh rate power supply for
indoor unit
Use normal kWh rate power supply for
indoor unit
(2) Gas boiler interconnection (2) Gas boiler interconnection
Gas boiler Gas boiler
(3) User interface (3) User interface
Only for remote user interface option Only for remote user interface option
(4) Domestic hot water tank (4) Domestic hot water tank
3 wire type SPDT 3 wire type SPDT
3 wire type SPST 3 wire type SPST
(5) Options (5) Options
230 V AC supplied by PCB 230VAC supplied by PCB
5 V DC pulse detection (voltage supplied
by PCB)
5VDC pulse detection (voltage supplied
by PCB)
Continuous Continuous current
DHW pump output Domestic hot water pump output
DHW pump Domestic hot water pump
Electrical and gas meter Electrical and gas meter
Ext. thermistor option External thermistor option
For safety thermostat For safety thermostat
Inrush Inrush current
Max. load Maximum load
Normally closed Normally closed
Normally open Normally open
Safety thermostat contact: 16 V DC
detection (voltage supplied by PCB)
Safety thermostat contact: 16VDC
detection (voltage supplied by PCB)
