Hitachi DH38MS [10/76] English
![Hitachi DH38MS [10/76] English](/views2/1081056/page10/bga.png)
Содержание
- Dh 38ms 1
- Hitachi 1
- 〱䍯癥牟䑈 䵓彅 1
- ご慢汥彄䠳㡍卟䕅 2
- English 7
- General power tool safety warnings 7
- ㅅ湧彄䠳㡍卟䕅 7
- English 8
- O i agi i 8
- Optional accessories sold separately 8
- Rotary hammer safety warnings 8
- Specifications 8
- Standard accessories 8
- Applications 9
- English 9
- Prior to operation 9
- Drilling and driving in operations for anchors 10
- English 10
- How to use the rotary hammer 10
- Using drill chuck chuck adapter 10
- English 11
- How to handle a core bit 11
- How to replace grease 11
- Maintenance and inspection 11
- English 12
- Guarantee 12
- Allgemeine sicherheitshinweise für elektrogeräte 13
- Deutsch 13
- 敲彄䠳㡍卟䕅 13
- Deutsch 14
- Sicherheitshinweise für den bohrhammer 14
- Sonderzubehör separat zu beziehen 14
- Standardzubehor 14
- Technische daten 14
- Deutsch 15
- Ggsssse 15
- Q l q md 15
- X i i l j s 15
- Anwendungsgebiete 16
- Deutsch 16
- Einsatz des bohrhammers 16
- Vor inbetriebnahme 16
- Bohren und eindrehen von ankern 17
- Deutsch 17
- Schmier fettwechse l 17
- Verwendung des bohrfutters und bohrfutteradapters 17
- Verwendung einer bohrkrone 17
- Deutsch 18
- Garantie 18
- Wartung und inspektion 18
- Deutsch 19
- Eààqviká 20
- Tenikes пр0е1д0п01н1ее аефале1ае haektpikoy_eptaaeioy_____________________ 20
- Прохохн 20
- 牥彄䠳㡍卟䕅 20
- Eààqviká 21
- Kanonika eeapthmata 21
- Npoaipetika eeapthmata nwàoúvrai çexwpiorá 21
- Npooyaaktika metpa da to nepiztpooiko s0ypoapanano 21
- Texnika xapakthpiztika 21
- Eààqviká 22
- Ecdapmotes 23
- Eààqviká 23
- Nas na xphsimonolhsete to nepietpo0ikos0ypoapanano 23
- Npin th aeitoypria 23
- 6 13 orioiopz s 24
- Aoi vsjoiaidvzodu noi aoinvuadl 24
- Hxozodu uomsdsij i 24
- Hzui3hhz 24
- Ihxoxodu 24
- Vdhixioz 24
- Vdhixkvz noi zvlnuiouoiailzhdx 24
- Vdlzihjv vij 24
- Zu1vauvi8 ivx zolvwhuadl z3ijda01l3v 24
- Ozvdj 01 313zh1zv1vxi1nv vn zuu 25
- Z0xj3v3 ivx hzhdhinaz 25
- Erryhsh 26
- Eààqvikà 26
- Dotyczace urzadzeñ elektrycznych 27
- Ogólne wskazówki bezpieczeñstwa 27
- Polski 27
- 㑐潬彄䠳㡍卟䕅 27
- Dane techniczne 28
- Mozliwe wyposazenie dodatkowe sprzedawane oddzielnie 28
- Polski 28
- Srodki ostroznosci przy korzystaniu z mtotowiertarki 28
- Wyposazenie standardowe 28
- Polski 29
- Jak uzywac mtotowiertarki 30
- Polski 30
- Przed uzyciem 30
- Zastosowanie 30
- Jak uzywac koronki rdzeniowej 31
- Jak zmienic smar 31
- Polski 31
- Uzywanie uchwytu wiertarskiego adaptora uchwytu 31
- Wiercenie i wbijanie uchwytu 31
- Gwarancja 32
- Konserwacja i inspekcja 32
- Polski 32
- Magyar 33
- Szerszâmgépekre vonatkozó âltalânos biztonsàgi figyelmeztetések 33
- 㕈畮彄䠳㡍卟䕅 33
- Fürôkalapâcs biztonsâgi figyelmeztetések 34
- Magyar 34
- Müszaki adatok 34
- Standard tartozékok 34
- Tetszés szerint vàlasztható tartozékok külön megrendelésre 34
- Magyar 35
- A fúrókalapács kezelése 36
- Alkalmazások 36
- Magyar 36
- A kenózsír lecserélése 37
- Ellenórzés és karbantartás 37
- Fúró és behajtó müvelet rôgzítõ horgonybetétekhez 37
- Fúrótokmány és tokmány adapter használata 37
- Magfúró koronafej alkalmazása 37
- Magyar 37
- G arancia 38
- Magyar 38
- Cestina 39
- Obecná varování tykající se bezpecnosti el prístroje 39
- 㙃穥彄䠳㡍卟䕅 39
- Bezpecnostnì varovànì pro vrtacì kladivo 40
- Cestina 40
- Doplnkové prìslusenstvì prodàvà se zvlàsf 40
- Parametry 40
- Standardnì prìslusenstvì 40
- Cestina 41
- Pouzitì 41
- Pred pouzitim 41
- Cestina 42
- Jak pouzìvat vrtaci kladivo 42
- Pouzívání sklícidla a adaptéru sklícidla 42
- Vrtání a zarázení hmozdinek 42
- Cestina 43
- Jak vyménit vazelìnu 43
- Jak zacházet s vrtákem 43
- Záruka 43
- Údrzbaakontrola 43
- Cestina 44
- Genel elektrikli alet güvenlík uyarilari 45
- Türkte 45
- 㝔畲彄䠳㡍卟䕅 45
- Kirici delící güvenlík uyarilari 46
- Standart aksesuarlar 46
- Stege bagli aksesuarlar aynca satihr 46
- Tekník 0zellíkler 46
- Türkge 46
- Aletì kullanmadan once 47
- Túrkçe 47
- Uygulamalar 47
- Ankraj íçín delík delme ve yerlestírme ísleri 48
- Ek mandren ve mandren adaptörünün kullanilmasi 48
- Kirici delicinin kullanilisi 48
- Tiirkçe 48
- Bakim ve nceleme 49
- Buat ucu nasil kullanilir 49
- Gres yagi nasil degìstìrìlìr 49
- Türkçe 49
- Garantí 50
- Türkge 50
- Avertismente generale privino siguranta in folosirea sculei electrice__________________________________ 51
- Romàna 51
- 㡒潭彄䠳㡍卟䕅 51
- Accesorii optionale se vând separat 52
- Accesorii standard 52
- Avertismente privino siguranta la folosirea ciocanului rotopercutor 52
- Romàna 52
- Specificati 52
- Romàna 53
- Cum se utilizeazà ciocanul rotativ 54
- Romàna 54
- Utilizare 54
- Înainte de utilizare 54
- Cum se manevreazä un burghiu de centruit 55
- Cum se schimbà lubrifiantul 55
- Operatii de forare si introducere a ancorelor 55
- Romàna 55
- Utilizarea mandrinei de gàurit a adaptorului mandrinei 55
- Garantie 56
- Romàna 56
- Ìntretinere gl verificare 56
- Slovenscina 57
- Splosna varnostna navodila za elektricno orodje 57
- 㥓汯彄䠳㡍卟䕅 57
- Opcijski dodatki prodajani loceno 58
- Slovenscina 58
- Specifikacije 58
- Standardni dodatki 58
- Varnostna opozorila v zvezi z uporabo rotacijskega kladiva 58
- Pred uporabo 59
- Slovenscina 59
- Uporaba 59
- Kako uporabljati rotacijsko kladivo 60
- Postopki vrtanja in zabijanja sidra 60
- Slovenscina 60
- Uporaba vrtalnega pritezala vmesnik pritezala 60
- Kako ravnati z osrednjim svedrom 61
- Kako zamenjati mazivo 61
- Slovenscina 61
- Vzdrzevanje in pregledi 61
- Garancija 62
- Slovenscina 62
- Общие правила безопасности при 63
- Работе с электроинструментом__________ 63
- Русский 63
- げ畳彄䠳㡍卟䕅 63
- Меры предосторожности для 64
- Перфоратора 64
- Русский 64
- Дополнительные аксессуары продаются отдельно 65
- Русский 65
- Стандартные аксессуары 65
- Технические характеристики 65
- Тпп 65
- Область применения 66
- Подготовка к эксплуатации 66
- Русский 66
- Эксплуатация перфоратора 66
- Анкеров 67
- Русский 67
- Сверление отверстий и установка 67
- Эксплуатация сверлильного патрона и адаптера к нему 67
- Бурильными коронками 68
- Замена смазки 68
- Как пользоваться полыми 68
- Проверка 68
- Русский 68
- Техническое обслуживание и 68
- Гарантия 69
- Русский 69
- ㅂ慣歟䑈 䵓彅 70
- Hitachi 74
- Hitachi koki 74
- Hitachi power tools czech s r o 75
- Hitachi power tools hungary kit 75
- Hitachi power tools netherlands b v moscow branch 75
- Hitachi power tools polska sp z o o 75
- Hitachi power tools romania 75
- Hitachi power tools österreich gmbh 75
- Head office in japan 76
- Hitachi koki co ltd 76
- Hitachi power tools europe gmbh 76
- K kato board director 76
- Representative office in europe 76
- Shinagawa intercity tower a 15 1 konan 2 chome minato ku tokyo japan 76
- Siemensring 34 47877 willich 1 f r germany 76
Похожие устройства
- Hitachi DH40MR Инструкция по эксплуатации
- Olympus E-PM2 1442 Black/Black Инструкция по эксплуатации
- Ariston ARTL 837 Инструкция по эксплуатации
- Hitachi DH40MRY Инструкция по эксплуатации
- Olympus E-PM2 1442 White/Silver Инструкция по эксплуатации
- Ariston ARXSF 105 Инструкция по эксплуатации
- Hitachi DH45MR Инструкция по эксплуатации
- Olympus E-PL5 1442 Black/Black Инструкция по эксплуатации
- Ariston ARXD 105 Инструкция по эксплуатации
- Hitachi DH50MR Инструкция по эксплуатации
- Olympus E-PL5 1442 White/Silver Инструкция по эксплуатации
- Panasonic NN-G315 Инструкция по эксплуатации
- Hitachi DH50MRY Инструкция по эксплуатации
- Olympus EZ-M1442-2R Black Инструкция по эксплуатации
- Panasonic NN-ST349 Инструкция по эксплуатации
- Hitachi DS14DCL Инструкция по эксплуатации
- Olympus EZ-M4015 R Silver Инструкция по эксплуатации
- Panasonic NN-G335 Инструкция по эксплуатации
- Hitachi DS14DBL Инструкция по эксплуатации
- Olympus EZ-M7530 Silver Инструкция по эксплуатации
English If you continue to turn the tool with slight pressure you can feel a spot where there is a hitch At that spot pull the grip to the direction of an arrow mark and insert the tool all the way until it hits the innermost end Releasing the grip reverts the grip and secures the tool in place 3 Pull the tool to make sure it is locked completely 4 To remove the tool fully pull the grip in the direction of the arrow and pull out the tool HOW TO USE THE ROTARY HAMMER NOTE Ensure that the wing bolt in the side handle is property tightened before using the tool 1 How to drill holes Fig 3 1 Pull the switch trigger after applying the drill bit tip to the drilling position 2 It is unnecessary to forcibly press the rotary hammer main body It is sufficient to slightly press the rotary hammer to an extent that shavings are freely discharged CAUTION Although this machine is equipped with a safety clutch if the drill bit becomes bound in concrete or other material the resultant stoppage of the drill bit could cause the machine body to turn in reaction Ensure that the main handle and side handle are gripped firmly during operation 2 How to chisel or demolish Fig 4 By applying the tool tip to the chiseling or demolishing position operate the rotary hammer by utilizing its empty weight Forcible pressing or thrusting is unnecessary 3 When drilling at rotation hammering CAUTION If you switch the selector lever during motor rotation the tool can start to rotate abruptly resulting in unexpected accidents Be sure to switch the selector lever when the motor is at a complete stop 1 Switching to rotation hammering a Push the button release lock andturn the selector lever clockwise b Align of the selector lever and f T of the lever holder as illustrated in Fig 5 c Release the button to lock the selector lever NOTE Turn the selector lever do not push the button to check if it is completely locked and make sure that it does not turn 4 When demolishing and chiseling at hammering CAUTION O If the selector lever is switched during motor rotation the tool can start to rotate abruptly resulting in unexpected accidents Make sure to switch the selector lever when the motor is at a complete stop O If the bull point or cold chisel is used at the position of rotation hammering the tool can start to rotate resulting in unexpected accidents Make sure that they are used at the position of hammering 1 Switching to hammering a Push the button release lock andturn the selector lever counterclockwise b Align of the selector lever and T of the lever holder as illustrated in Fig 6 g c Release the button to lock the selector lever NOTE Turn the selector lever do not push the button to check if it is completely locked and make sure that it does not turn 2 When fixing working positions of tools such as cold chisel etc a Push the button release lock and turn the se lector lever Align of the selector lever and of the lever holder as illustrated in Fig 7 b Release the button to lock the selector lever c Turn the grip as illustrated in Fig 8 and fix the tool to the desired working direction Id Switch the selector lever to hammering according to the procedures mentioned in the above item 1 and secure the position of the tool 5 Warming up Fig 9 The grease lubrication system in this unit may require warming up in cold regions Position the end of the bit so makes contact with the concrete turn on the switch and perform the warming up operation Make sure that a hitting sound is produced and then use the unit CAUTION When the warming up operation is performed hold the side handle and the main body securely with both hands to maintain a secure grip and be careful not to twist your body by the jammed drill bit DRILLING AND DRIVING IN OPERATIONS FOR ANCHORS 1 When a taper shank adapter is used Fig 10 1 Install drill bit with taper shank in the taper shank adapter 2 Turn the power on and drill a base hole to the depth sounded by indicating groove on the drill bit 3 After cleaning out dust with a syringe attach the plug to the anchor tip and drive in the anchor with a manual hammer 4 To remove the drill bit taper shank insert the cotter into the slot of the taper shank adapter and strike the head of the cotter with a manual hammer supporting on a rest Fig 11 USING DRILL CHUCK CHUCK ADAPTER Note that this machine can be used at rotation only if separately sold parts such as drill chuck and chuck adapter are attached Use it with the selector lever positioned at rotation hammering CAUTION During operation be sure to grip the handle and the side handle firmly to prevent your body from swaying 1 Switching to rotation hammering For switching to rotation hammering follow the same procedures mentioned in 3 When drilling at rotation hammering 2 Attaching chuck adapter to drill chuck Fig 12 a Attach the chuck adapter to the drill chuck b The SDS max shank of the chuck adapter is equivalent to the drill bit Therefore follow the same procedure as How to install tool for attaching and detaching
