7
English
5) Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool
is maintained.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach of
children and infirm persons.
PRECAUTION ON USING CUTTER
1. Never attach any tool except the diamond wheel as
specified by the manufacturer.
Do not operate the cutter while applying water.
2. Always check the diamond wheel before starting the
machine. If it is cracked, broken or bent, do not use
it. Carefully start the machine to check for other
abnormalities.
3. Using the diamond wheel to cut metal will shorten
its service life or will result in breakage. Never use
the diamond wheel to cut metal.
4. Start working only when maximum rotation speed
is reached.
5. Excessive force overloads the motor. Always cut
with a cutting depth of 5mm or less.
6. Do not use this machine to cut asbestos.
7. In operations using a cutting wheel, if flame comes
out, cover the dust collection adaptor with a rubber
cap and be sure to wear protective glasses.
SPECIFICATIONS
Voltage (by areas)* (110V, 230V)
Power input* 1300W
No-load speed 11000 min
–1
Dimensions of diamond wheel
Max. cutting depth 33mm
Weight (without cord and diamond wheel) 2.9kg
* Be sure to check the nameplate on product as it is subject to change by areas.
Outer dia. 125mm
Thickness 2.0mm
Hole dia. 22.2mm
STANDARD ACCESSORIES
(1) Wrench ........................................................................ 1
(2) Adaptor ....................................................................... 1
(3) Side handle ................................................................ 1
Standard accessories are subject to change without notice.
APPLICATION
䡬 Cutting or scribing concrete
䡬 Cutting or scribing tile
䡬 Cutting or scribing stone
䡬 Cutting or scribing roof tile
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a power receptacle while
the power switch is in the ON position, the power
tool will start operating immediately, which could
cause a serious accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Checking and installing the diamond wheel
Check the diamond wheel is a specified one and
is not cracked, broken or bent. Check the diamond
wheel is installed securely. For installation, refer to
“Installing/removing diamond wheel”.
5. Fitting and adjusting the dust collection cover (Fig. 1)
The dust collection cover is a protective device to
prevent injury should the diamond wheel shatter
during operation. Ensure that the cover is properly
fitted and fastened before commencing cutting
operation. By slightly loosening the setting screw,
the dust collection cover can be turned and set at
any desired angle for maximum operational
effectiveness. Ensure that the setting screw is
thoroughly tightened after adjusting the dust
collection cover.
6. Confirm the spindle lock mechanism
Confirm that the spindle lock is disengaged by
pushing push button two or three times before
switching the power tool on (See Fig. 1).
7. Cutting depth adjustment (Fig. 2)
Lowering the wing nut will loosen and raising it will
tighten.
Loosening the wing nut and moving the slide guide
will allow adjustment of the cutting depth.
CAUTIONS
䡬 Leaving the wing nut loosened may result in injury.
Securely tighten the wing nut after adjusting the
cutting depth.
01Eng_CM5SM_EE 12/13/07, 18:437
