10
APPLICATIONADVICE
For trimming a hedge at a uniform height level
- fasten a piece of string along the length of the hedge
at the desired height
- trim the hedge just above this string
Recommended cutting/trimming times (Western Europe)
- trim hedges with deciduous leaves in June and
October
- trim evergreen hedges in April and August
- trim conifers and other fast-growing shrubs every 6
weeks from May until October
MAINTeNANCe / serVICe
This tool is not intended for professional use
Keep tool, charger and cutting blades clean
! unplugchargerfrompowersourcebefore
cleaning
! alwaysremovethebatterybeforecleaning
- clean the tool with a damp cloth (do not use cleaning
agents or solvents)
- clean ventilation slots J 2 regularly with a brush or
compressed air
- after use, always carefully clean and lightly lubricate
the cutting blades
! weargloveswhenhandlingorcleaningthe
cuttingblades
Regularly check the condition of the cutting blades and
the tightness of the blade bolts
Regularly check for worn or damaged components and
have them repaired/replaced when necessary
Sharpening the cutting blades
! removebatteryfromtool
- remove cutting blades from tool before sharpening
- sharpen the cutting blades with a small and smooth
le, in case a solid object damaged them
- we advise you, however, to have the blades sharpened
by a specialist
- lubricate the cutting blades after sharpening
Storage ¡
- store the tool indoors in a dry and locked-up place,
out of reach of children
- securely mount storage rail K on the wall with 4 screws
(notsupplied) and horizontally leveled
- use blade guards L 2 when storing the tool
- lubricate the cutting blades before storing the tool
If the tool/charger should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool or charger undismantled together with
proof of purchase to your dealer or the nearest SKIL
service station (addresses as well as the service
diagram of the tool are listed on www.skil.com)
- in case of a defective charger send bothchargerand
battery to your dealer or the SKIL service station
TroUBlesHooTING
The following listing shows problem symptoms, possible
causes and corrective actions (if these do not identify
and correct the problem, contact your dealer or service
station)
! switchoffthetoolandremovethebatterybefore
investigatingtheproblem
Tool operates intermittently
- internal wiring defective -> contact dealer/service
station
- on/o switch defective -> contact dealer/service
station
Motor runs but blades remain stationary
- internal fault -> contact dealer/service station
Cutting blades hot
- cutting blades blunt -> have blades sharpened
- cutting blades have dents -> have blades inspected
- too much friction due to lack of lubricant -> lubricate
blades
eNVIroNMeNT
Donotdisposeofelectrictools,batteries,
accessoriesandpackagingtogetherwithhousehold
wastematerial (only for EU countries)
- in observance of European Directive 2012/19/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol @ will remind you of this when the need for
disposing occurs
The nickel-metalhydride battery must be kept separate
from the natural environment and should not be disposed
of as normal domestic waste (symbol # will remind you
of this when the need for disposing occurs)
! priortodisposalprotectbatteryterminalswith
heavytapetopreventshort-circuit
- dispose of the batteries at an ocial collection point
for batteries
! batteriesmayexplodewhendisposedofinfire,
sodonotburnbatteryforanyreason
deClArATIoN oF CoNForMITY
We declare under our sole responsibility that the product
described under “Technical data” is in conformity with the
following standards or standardization documents: EN
60335, EN 60745, EN 61000, EN 55014 in accordance
with the provisions of the directives 2006/95/EC,
2004/108/EC, 2006/42/EC, 2000/14/EC, 2011/65/EU
Technicalfileat: SKIL Europe BV (PT-SEU/ENG1),
4825 BD Breda, NL
¹ÊÁÂÆιÆ¼½ÊÇǾ¼½Æ
ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿
ÍÊÇȽƓˁ˅ʿ˂ʽ¼¹Ɠ
Ĺ¾ÁÂÿʹ¹¾
ÈÈÊÇιÄ¹Æ¹¿½Ê
24.02.2014
10
NoIse/VIBrATIoN
Measured in accordance with EN 60745 the sound
pressure level of this tool is 58 dB(A) and the sound
power level 78 dB(A) (standard deviation: 3 dB), and the
