Appendix B: FBV Foot Controllers
B•11
FBV Longboard - Footswitch & Pedal Mappings
Footswitch
Label
POD HD Pro
Function
FBV LCD Screen Footswitch
LED
Description
CHANNEL A
Selects Preset A
(ABCD Mode)
Displays current
Preset name
Lit when
selected
Loads Preset A of
current Bank
FS5 On/Off
(FS 5-8 Mode)
Displays current
Preset name
Lit when
Block active
Toggles the “FS5”
assigned Amp/FX
Block
CHANNEL B
Selects Preset B
(ABCD Mode)
Displays current
Preset name
Lit when
selected
Loads Preset B of
current Bank
FS6 On/Off
(FS 5-8 Mode)
Displays current
Preset name
Lit when
Block active
Toggles the “FS6”
assigned Amp/FX
Block
CHANNEL C
Selects Preset C
(ABCD Mode)
Displays current
Preset name
Lit when
selected
Loads Preset C of
current Bank
FS7 On/Off
(FS 5-8 Mode)
Displays current
Preset name
Lit when
Block active
Toggles the “FS7”
assigned Amp/FX
Block
CHANNEL D
Selects Preset D
(ABCD Mode)
Displays current
Preset name
Lit when
selected
Loads Preset D of
current Bank
FS8 On/Off
(FS 5-8 Mode)
Displays current
Preset name
Lit when
Block active
Toggles the “FS8”
assigned Amp/FX
Block
TAP TEMPO
Sets Tap Tempo No Change Blinks at
tempo
Tap to set tempo rate
Tuner Mode On/
Off
Displays Tuner Blinks at
tempo
Hold to enter/exit
Tuner Mode
Pedal 1
Toe Switch
Toe Switch No change No change Assignable as a
footswitch
