LINE 6 POD HD Pro [89/135] The line 6 audio midi devices panel

USB Audio

9•3

The POD HD Pro Record Send

As shown above, the Record Send is the virtual “pipeline” that carries your POD HD-

processed, 24-bit digital signal across the USB connection, making it available to your

audio software as an input signal for recording.

The Record Send appears as an available audio input/recording device within your audio

software. Simply select this Send as the input for your audio track and you’ll be able to

record your POD HD Pro signal. The level of the signal fed to the Send is affected by your

POD HD Pro controls: Mixer block Volume A & B, Amp Model Drive & Volume, FX

Model Gain controls, Volume Pedal, etc., (but not the Master Volume knob). For the best

recording quality, watch the input meters provided in your software and adjust your level

to be at least halfway up, but never “clipping.”

Note that the type of audio signal fed to the Record Sends is controlled by the Output

Mode

setting found in the POD HD Pro Setup:Outputs screen. For most USB recording

situations, you’ll likely want to set this to “Studio/Direct.” Please see “Page 4, Setup:

Output Options” on page 2•8

for more info.

The Line 6 Audio-MIDI Devices Panel

The Line 6 Audio-MIDI Devices utility is the place where you conﬁgure various audio

driver settings. The options in the Line 6 Audio-MIDI Devices dialog are slightly different

if you are on a Mac® versus a Windows® system. See the following descriptions that

match your setup: For Mac® see next section, or for Windows® see page 9•8.
