USB Audio
9•1
uSb audiO
In this chapter, we’ll cover the USB audio capabilities of POD® HD Pro. With the
installation of the Line 6 USB audio driver, you can use POD HD Pro as a high quality
audio interface for your Mac® or Windows® computer!
The Line 6 USB Audio Driver
Before you connect POD HD Pro to your computer, it is recommended that you download
and install the free Line 6 POD HD Pro Edit software. This installs the necessary Line
6 USB Audio Driver, as well as the Line 6 Monkey update utility (also see “Appendix
A: Line 6 Monkey” on page A•1). The latest POD HD Pro Edit installer, as well as
individual installers for the Driver & Line 6 Monkey, are also always available from http://
line6.com/software.
NOTE: The POD HD Pro USB Device Driver requires Mac OS® X version 10.5
(Leopard®) or later.
The Line 6 Software Downloads site - selecting the POD HD Pro Edit software
Once installation is complete, just connect your device directly to a USB port on your
computer (not into a USB hub) and power on your POD HD Pro. Note that POD HD Pro
requires the use of a USB 2.0 port on your computer.
Also see the POD HD Pro Edit Installer Guide and the POD HD Pro Edit Pilot’s
Guide
, available from http://line6.com/support/manuals.
