Appendix B: FBV Foot Controllers
B•17
ENTER
DBL PRESS TO ASSIGN CTL
MOVE
AMP & FX ON / OFF
Note: When a Controller is assigned to any FX Model parameter, manually editing this
parameter’s value will result in changing the Controller’s MIN or MAX value. For example,
if the EXP-1 Pedal Controller is assigned to a Wah FX Model’s Position parameter, select
the Wah Model, go to its Edit View screen, and select the Position parameter. If you turn
multifunction knob #4 when the Pedal is near the “heel” position, the MIN value is
adjusted. If you turn the knob when the Pedal is near the “Toe” position, the MAX value
is adjusted.
The Controller Assign screen is then displayed specifically for the selected Model. In our
example, it is the Digital Delay W/Modulation. Use the Multi-function Knobs 1-4 to
configure the controller assignment options.
The Controller Assign screen
