Features & Functionality

3•7

• The FX Loop is capable of stereo, just like any stereo-output FX Model, provided

that you utilize both stereo pairs of the SEND & RETURN jacks. If you use only the

Left SEND or RETURN jack, the FX Loop signal is summed to mono.

• The above rules also apply within each of the parallel Paths A and B, since

these are each stereo signal paths as well. The Mixer Block offers Pan controls to

independently adjust the stereo balance of each of these Paths before they are fed

into the ﬁrst “Post” FX (or Amp Block, if the Amp is placed here), immediately

following the Mixer.

• Please also see “Amp Model Positioning” on page 6•1 for additional signal ﬂow

information.

FX & Amp Block FBV Footswitch Assignment

Any of the FX and Amp Blocks can also be conﬁgured with a “FS” (Footswitch) assignment

to utilize a connected Line 6 FBV™ Controller to remotely toggle the Block’s Model On/

Off. For details, please see “Amp & FX Block Footswitch Assignment” on page B•18.

It is worth noting here that, when the Setup - FS MODE option (see “Page 1, Setup:Utilities

Options” on page 2•2) is set to “FS 5-8,” your FBV device’s A, B, C & D footswitches will

trigger the FS 5-8 assigned Blocks. To create and edit FS assignments, select the desired FX

or Amp Block within the Signal Flow View, then hold the VIEW button. This displays the

FS ASSIGN screen. All assignments are saved per Preset.

The Footswitch Assign screen - use Knob 1 to create or edit a Block’s FS assignment
