Looper Mode Footswitch Behaviors
When the POD HD Pro Looper Mode is active, pressing the connected FBV Looper
footswitch functions automatically transmits the following MIDI CC messages. These are
global MIDI CC assignments and cannot be edited.
Note: These assignments are also the same MIDI CC messages that POD HD Pro and POD
HD500 devices respond to for these Looper Mode functions. Therefore, if you are sending
MIDI Out from your POD HD Pro to the MIDI In of another POD HD Pro or POD
HD500 device, its Looper functions can be switched simultaneously!
Looper Mode Footswitches - MIDI CC Transmit Reference
Footswitch MIDI CC # Value
FS1 (Undo) 063 127
FS2 (Play Once) 062 127
FS3 (Pre/Post) 067 Toggle: Pre = 0-63, Post = 64-127
FS5 (Rec/Overdub) 060 Toggle: Overdub = 0-63, Record = 64-127
FS6 (Play/Stop) 061 Toggle: Stop= 0-63, Play = 64-127
FS7 (1/2 Speed) 068 Toggle: Full = 0-63, Half = 64-127
FS8 (Reverse) 065 Toggle: Forward = 0-63, Reverse = 64-127
