Appendix B: FBV Foot Controllers

B•18

• Parameter (Knob 1): Select the parameter for the current Model that you want to

control.* For our example, we’ll choose the Mix parameter.

• Controller (Knob 2): Select the controller that you want to assign to the parameter.

Choose Off to have no assignment, or choose EXP 1, EXP 2, Variax Vol or Variax

Tone.

• Min. Value (Knob 3): Set the desired parameter value for the Pedal’s “heel” position.

• Max. Value (Knob 4): Set the parameter value you’d like for the Pedal’s “toe” position.

* Note that when you add a Wah FX Model to your tone, the “Position” parameter for the

Wah is automatically assigned to EXP 1. Likewise, when adding a Volume or Pan FX Model,

its Position parameter is automatically assigned to EXP 2. This will result in multiple items

assigned to these EXP Pedals if you already have existing Pedal assignments. For all Factory

Presets that already include a Wah, Volume or Pan, these are typically already assigned as

well. Be sure to remove any unwanted Model’s EXP assignment for your Preset.

To create a controller assignment to an FX Loop parameter, simply select the FX Loop

Block within the Signal Flow View and go to the Controller Assign screen, as described

above.

The Controller Assign options for the FX Loop

Amp & FX Block Footswitch Assignment

FBV footswitches, as well as the on-board Pedal’s “Toe Switch,” can be conﬁgured to

toggle any of the Amp or FX Blocks On/Off. You can reference the current Preset’s FX

footswitch assignments within the Performance View screen, as covered on page B•4.

These settings are saved per Preset.
