Appendix C: MIDI
C•3
POD HD Pro - MIDI Control Reference
MIDI CC # Value Function
Additional Controls
064 64-127 = Tap Tap Tempo - Enter Tap Tempo
069 0-63 = Off 64-127 = On Tuner Mode On/Off
Bank & Program Change Messages
POD HD Pro will respond to incoming MIDI Bank & Program Change messages as follows.
• Load Set List:fromyourMIDIcontrollerdevice,sendaBankChangeCC0(Bank
MSB),CC32(LSB)messagewithavalueof0(forSetlist1),1(forSetlist2),etc.,
followedbyaProgramChangemessage(Value0-63forPreset01A-16D)forthe
desired Preset within the Set List. The Set List and Preset are loaded on POD HD
Pro.
• Load a Preset within the current Set List: Send a Program Change message (Value
0-63forPreset01A-16D)forthedesiredPresetwithinthecurrentSetList.
When using the POD HD Pro hardware options for navigating Presets (the PRESETS
knob, 4-Way Nav. Disc, and FBV footswitches A, B, C, D*) the device will automatically
transmit MIDI a Program Change message corresponding to the selected Preset. These
messages are transmitted to the MIDI OUT/THRU DIN. It is also possible to configure
Footswitches to send Bank and Program Change messages - see the next section.
*Note that you’ll need to set your “Footswitch Mode” Setup option to “ABCD” for this
specific Preset data to be sent when pressing the FBV FS5 - FS8 footswitches to change the
Preset on POD HD Pro - see “Page1,Setup:UtilitiesOptions”onpage2•2.
This feature allows you to use POD HD Pro to control external devices by sending the
following MIDI Bank & Program Change commands. Also note that if you connect to
anotherLine6PODHDProorPODHD500,theconnecteddevicewillfollowtheSetlist
& Preset loading behavior of the initial POD HD Pro!
