FX Models
7•11
Delay Models - Parameter Reference Table
Model Parameters
Echo Platter Time Fdbk Wow/Flt Drive Mix
Echo Platter Dry Time Fdbk Wow/Flt Drive Mix
Analog W/Mod Time Fdbk ModSpd Depth Mix
Analog Echo Time Fdbk Bass Treble Mix
Auto-Volume Echo Time Fdbk ModDep Swell Mix
Multi-Head Time Fdbk Heads 1-2 Heads 3-4 Mix
Common Parameters
The following parameters are common to most Delay FX Models.
• Time: Adjusts the delay/repeat time, with higher settings providing longer delays.
Time can be adjusted to a MS value or Note Division:
• Choosing a MS value provides a specific time in milliseconds.
• Choosing a Note Division value provides a time that is based on the current Tap
Tempo (see “Tap Tempo” on page 1•5).
• Fdbk (Feedback): Sets the number of delayed repeats.
• Depth: Some delays include modulation. These will typically include a Depth
parameter to adjust the intensity of the pitch modulation applied to the repeats.
• ModSpd: Control the speed of the pitch modulation.
• Mix: Sets the balance of the “Dry” and “Wet” signals. At 0% no effect is added to
your signal; at 100% you will hear the delayed signal only.
