Appendix C: MIDI
C•2
Controlling POD HD Pro Functions via MIDI
POD HD Pro Footswitch & Pedal assignments, Looper functions and more can be can
controlled remotely via a MIDI Controller device connected to the POD HD Pro MIDI
IN port. The following reference table shows the necessary MIDI CC settings to configure
your MIDI Controller device to access these POD functions.
POD HD Pro - MIDI Control Reference
MIDI CC # Value Function
Pedal & Footswitch Assignments
001 0 - 127 EXP-1 Pedal Assignment
002 0 - 127 EXP-2 Pedal Assignment
051 0 - 127 Toggles FS1 Assignment On/Off
052 0 - 127 Toggles FS2 Assignment On/Off
053 0 - 127 Toggles FS3 Assignment On/Off
054 0 - 127 Toggles FS4 Assignment On/Off
055 0 - 127 Toggles FS5 Assignment On/Off
056 0 - 127 Toggles FS6 Assignment On/Off
057 0 - 127 Toggles FS7 Assignment On/Off
058 0 - 127 Toggles FS8 Assignment On/Off
059 0 - 127 Toggles EXP Toe Switch Assignment On/Off
Looper Controls
060 0-63 = Overdub, 64-127 = Record Looper Record/Overdub Switch
061 0-63 = Stop, 64-127 = Play Looper Play/Stop Switch
062 64-127 = Play Once Looper Play Once Switch
063 64-127 = Undo Looper Undo Switch
065 0-63 = Forward 64-127 = Reverse Looper Forward/Reverse Switch
067 0-63 = Pre 64-127 = Post Looper Pre/Post Position Switch
068 0-63 = Full 64-127 = Half Looper Full/Half Speed Switch
099 0-63 = Off 64-127 = On Looper Mode On/Off
