Appendix C: MIDI

C•6

Use the and Nav. Disc buttons to select the desired FBV footswitch or Exp Pedal

control. The selected control is indicated by the down arrow (such as FS2 in the above

screen). Once selected, the control’s MIDI options can be edited using the Multi-function

Knobs 1-4. Each respective control  in the screen indicates if it has an active MIDI

assignment:

FS1 with MIDI Assignment FS1 with no MIDI Assignment

• MIDI Channel (Knob 1): Select the MIDI Channel on which the selected control

will transmit its MIDI command.

• None:SendnoMIDIdata.(Notethatyouwon’tseeKnob2-4optionsappear

until you select an option other than “None.”)

• 01 - 16: Choose the MIDI Channel on which to transmit the selected control’s

messages.

• Base: Sets the control to follow the current “system” MIDI Channel, as set in the

device Setup (see “Page 6, MIDI/Tempo Options” on page 2•10). This is a handy

feature to have any Presets’ MIDI Controls set to “Base” to dynamically follow the

common Setup -MIDI Channel value.

• Message Type (Knob 2): Select the type of MIDI message sent by the selected

control.

• FS1 - FS8, LOOPER, TAP and EXP TOE SWITCH footswitches can each be

assigned to send MIDI CC, CC Toggle, Program Change (ﬁxed), Bank Change

(ﬁxed) or Note On messages.

• The EXP1 and EXP2 pedal controls can be assigned to each send one MIDI CC

with a deﬁnable Value Range, which allows you to sweep a variable parameter on

your target device.

• CC/Program/Bank # (Knob 3): Selects further options, depending on the Message

Type selected (Knob 2).
