Stiga COMBI 48 SQ H [15/228] Iëni 5

STARTING THE ENGINE (hot starting)

•) Follow the whole cold-starting procedure

with throttle control (1) in «FAST» position.

USE OF THE ENGINE IN OPERATION

When mowing, use the engine at its max rpm by

moving the throttle control to «FAST» position.

Keep your hands away

from the silencer and surrounding areas

that can become extremely hot. With the

engine running, do not get loose-fitting

clothing (ties, scarves, etc.) or hair closer to

the top part of the engine.

Do not operate on over 20°

inclines to prevent malfunctioning of the

engine.

STOPPING THE ENGINE DURING

MOWING

a) Move the throttle (1) to «SLOW».

b) Stop the engine as described in the ma-

chine’s instructions manual; in the case of

engines with electric ignition, move the throt-

tle to «STOP», or turn the key (3) (if present)

to «OFF».

STOPPING THE ENGINE AFTER

MOWING

a) Move the throttle (1) to «SLOW».

b) Stop the engine as described in the ma-

chine’s instructions manual; in the case of

engines with electric ignition, move the throt-

tle to «STOP», or turn the key (3) (if present)

to «OFF».

c) When the engine is cold, disconnect the

spark plug (4) and remove the key (3) (if pres-

ent).

d) Remove all traces of debris or dirt from the

engine and especially around the exhaust

silencer to reduce the risk of fire

CLEANING AND STORAGE

a) Do not spray with water or use hydraulic

lances to clean the exterior of the engine.

5.7

5.6

5.5

IMPORTANT



WARNING!

5.4

5.3

b) Preferably use a compressed air gun (max. 6

bars), to prevent debris, dirt or dust from pen-

etrating inside the machine.

c) Store the lawnmower (and the engine) in a dry

place, sheltered from severe weather condi-

tions and sufficiently ventilated.

LONG STORAGE (over 30 days)

In case the engine has to be stored for a long

time (for example at the end of the season), a

few precautions are needed to help the future

start-up.

a) Drain fuel from tank to prevent build-ups

inside the tank.

b) Remove the spark plug and pour inside the

spark plug hole about 3 cl of clean engine oil.

Close the hole with a cloth, then pull, slowly

and carefully, the starting rope so that, with a

few engine revolutions, the oil will be distrib-

uted on the cylinder inner walls. Reinstall the

spark plug without connecting the cable cap..

5.8
