Stiga 75 YEARS LIMITED EDITION [57/192] Starting driving

ENGLISH

3. Set the gear control to neutral (N).

4. Starting cold engine – put the throttle control in

the choke position.

Starting warm engine – set the throttle control

to full throttle (approx. 2 cm behind the choke

position).

5. Depress the clutch – brake pedal fully.

6. Turn the ignition key and start the engine.

7. Once the engine has started, move the throttle

control gradually to full throttle (approx. 2 cm

behind the choke position) if the choke has been

used.

8. When starting from cold, do not make the ma-

chine work under load immediately, but let the

engine run for a few minutes first. This will al-

low the oil to warm up.

5.5.2 Starting driving

The machine must not be

driven in any direction on

slopes with a gradient

greater than 10º.

See fig. 11.

Always operate the ma-

chine at full throttle when driving.

1. Depress the clutch – brake pedal fully.

2. Engage the desired gear.

3. Slowly release the clutch-brake pedal fully and

the machine starts to move in the desired direc-

tion.

4. Engage the cutting deck.

5.5.3 Driving tips

Ensure that the correct amount of oil is in the en-

gine. Especially when driving on slopes. See 5.3.

Be careful when driving on slopes. No

sudden starting or stopping when mov-

ing up or down a slope. Never drive

across a slope. Move from the top down,

or from the bottom to the top.

Reduce the speed on slopes and when

making sharp turns to prevent the ma-

chine from tipping over or you losing

control.

Do not turn the steering wheel to full

lock when driving in top gear and at full

throttle. The machine can easily topple

over.

Never drive with the engine casing

open.

Never drive with the deck connected in

the transport position. This will damage

the deck’s drive belt.

5.6 CUTTING

5.6.1 Cutting height

The best cutting results are achieved when the

when the top third of the grass is cut off. I.e. 2/3 of

the length of the grass remains.

If the grass is long and has to be cut significantly,

cut twice using different cutting heights.

Do not use the lowest cutting heights if the lawn

surface is uneven. This would entail a risk of the

blades being damaged against the surface and the

lawn’s top layer of soil being removed.

5.6.2 Composting/rear ejection

The deck can cut grass in two ways:

• Compost the grass into the lawn.

• Eject the grass behind the deck.

The deck is set for composting on delivery. In or-

der to eject the grass behind the deck, the plug

(16:P) must be removed.

See “6.16.2” and “6.16.3” on how to dismantle and

assemble the cutting deck.

5.6.3 Mowing advice

In order to achieve optimum mowing results, fol-

low the advice below:

• Cut frequently.

• Run the engine at full throttle.

• The grass should be dry.

• Use sharp blades.

• Keep the underside of the cutting deck clean.

5.7 STOP

If the machine is left unattended, re-

move the ignition key.

The engine may be very warm immedi-

ately after it is shut off. Do not touch the

silencer, cylinder or cooling fins. This

can cause burn injuries.

1. Depress the clutch – brake pedal fully.

2. Set the gear control to neutral (N).

3. Disengage the cutting deck.

4. Allow the engine to idle 1 - 2 minutes. Then

turn the ignition key to the stop position so that

the engine stops.

5. Lock the parking brake.
