D-Link DPH-150SE [10/53] Alert transfer
![D-Link DPH-150SE [10/53] Alert transfer](/views2/1013396/page10/bga.png)
Multi-line calls
DPH-150S supports 2 SIP lines max,that is user could use 2 SIP accounts to register and
make calls. System will use SIP 1 as default line to call. User can use the to select
the line to call.
There are most two calls at the same time. Screen will display the incoming call number
when user is keep talking. You can press the Soft1 (Answer) to accept it, and hold the first one (if
you want to use this function, you need enable Call Waiting of the phone first). Use Soft1 (Switch)
to switch the two calls to talk. User can also use Soft1 (Conf) to make the second call when there
is just an active call.
3.1.3. Ending a call
Hangs up by handset onhook.
Hangs up by press when in hands-free.
Hangs up a call in call waiting state.
When there are two calls,user might use Soft1(Switch)to switch to the call you want to hang up
first. Then press # or press Soft3(Close) key to finish talk, and phone will switch to the other call
automatically.
Note:it is no use to press # to finish talk, if there is only one current call.
3.1.4. Transferring a call
Blind Transfer
During talk, press ,and then dial the number that you want to transfer to, and press #.
Phone will transfer the current call to the third party. After finishing transfer, the call you talk to will
be hanged up. User can not select SIP line when phone transfers call.
Attended Transfer
During talk, press and input the number that you want to transfer to and press Soft2
(Send). After that third party answers, then press to complete the transfer. (You need
enable call waiting and call transfer first). If there are two calls, you can just talk to one, and keep
hold to the other one. The one who is keep hold can not speak to you or hear from you. In this
status, user can press * or Soft2 (Conf) to make calls mode in conference mode. If user wants to
stop conference, user can press Soft1 (Split). (User must enable call waiting and three way call
first).
Note: the server that user uses must support RFC3515 or it might not be used.
Alert Transfer
During talk, press firstly, then press Soft2(Send) after inputting the number that you
want to transfer. You are waiting for connection, now, press Soft2(Transf) and the transfer will be
done. (To use this feature, you need enable call waiting and call transfer first)
3.1.5. Calling Hold
During talking, user could press to hold the current call. Press again to
unhold the call or switch the call active. This feature is also available in 3-way conference call.
3.1.6. 3-way conference call
User can press Soft1 (Conf) to dial the line2 (press Soft1(Answer) to answer the call directly
if this call is from line2)during talking with line1. After line2 connect, user can press Soft2 (Conf) or
* to enter into conference mode. To back to line1 from conference, please press Soft1 (Split); to
end the call, please press Soft3 (End).
10
