![D-Link DPH-150SE [38/53] Phone book](/img/pdf.png)
D-Link DPH-150SE [38/53] Phone book
![D-Link DPH-150SE [38/53] Phone book](/views2/1013396/page38/bg26.png)
[1-8]xxx: Cause extensions 1000-8999 to be dialed immediately
9xxxxxxx: Cause 8 digit numbers started with 9 to be dialed immediately
911: Cause 911 to be dialed immediately after it is entered.
99T4: Cause 99 to be dialed after 4 seconds.
9911x.T4:Cause any number started with 9911 to be dialed 4 seconds after dialing ceases.
Notice: End with “#”, Fixed Length, Time out and Digital Map Table can be used simultaneously,
System will stop dialing and send number according to your set rules.
4.3.4.4. Phone Book
You can input the name, phone number and select ring type for each name here.
Phone Book
Field name explanation
Shows the detail of current phonebook.
Name
Shows the name corresponding to the phone number
Number Shows the phone number
Ring Type Shows the ring type of the incoming call.
Click “Modify” to change the selected information and click the “Delete” to delete the selected
record.
Notice: the maximum capability of the phonebook is 500 items
38
