Status
Field name Explanation
WAN
Shows the configuration information on WAN port, including the
connect mode of WAN port (Static, DHCP, PPPoE), MAC address, the
IP address of WAN port .
LAN Shows the configuration information on LAN port, including the IP
address of LAN port, ON or OFF of DHCP mode of LAN port.
Phone Number Shows the phone numbers provided by the SIP LINE 1-2 servers.
The last line shows the version number and issued date.
4.3.1.2. Wizard
Wizard
Field Name Explanation
16
