F_UNAUTOREDIA
L
Cancel redial function.
F_DND Do not disturb function.
F_MWI MWI(message waiting indication) function.
F_CFWD Call forward function.
F_CALLERS Like the Callers key.
F_MEMO Like the Memo key.
F_REC Record function (record on server).
User can implement BLF/PRESENCE/MWI/SPEED DIAL features by Memory Key.
/b Busy Lamp Field: Based on Asterisk, it can be used to check the status (Idle,ring,busy) of
the pointed phones. It is helpful to operator to know the status of the phone which he will
switch to.
User can configure the BLF like: 300 is rogatory number, @1 means SIP1, of course, user can
configure as @2(SIP2); if don’t use this, simply says 300/b, it will use SIP1 as default. /b means
use BLF feature.
When this configuration enable, the phone will subscribe the status of pointed phone each 60s:
LED off means Idled, LED flash means ring and LED on means busy.
/m MWI (Message waiting indication), means the number of this key is the number of
voicemail
User can configure MWI function according to the above chart: 8000 is mailbox number, @1 is
using SIP1, user also can configure @2(SIP2),the rest lines can be deduced by analogy, if no use,
is 8000/m,it will pass the SIP1 line in default,/m means MIW function is using.
If there’s new voicemail, LED will blink and shows new message, after receiving, server will send
current mail info to phone, after receiving new MWI order, LED will respond, if LED light is off, it
means no new voicemail.
/p Presence, means phone can check the status of other phone that has relevant numbers.
User can configures presence function according to the above chart: 500 is number that search
caller, @1 is using SIP1, user also can configure @2(SIP2),the rest lines can be deduced by
analogy, if no use, is 500/p, it will pass the SIP1 line in default, /p means presence function is
using.
At this moment, press this button, it can show the correponding phone’s status (on, off, fail,) which
LED don’t remind.
/f speed dial, user configure it as same time as above attribute, after configuring, phone will
implement above function in priority, then considering to perform speed dial
/i PUSH TO TALK, user presses this button in standby, the phone can call other phone and the
other phone will auto answer.
User can configure PUSH TO TALK according to the chart: 700 is number of callee.
After configuring, the phone can call 700 and make 700 auto answer by pressing this button.
3.2.7. Call pickup
Call pickup is implemented by simulating pickup function of PBX. it’s that, when A calls B, B rings
but no answer, at this moment, C can hook off and input an appointed prefix plus B’s number, pick
up A’s call and talk with A.
The following chart shows how to configure an appointed prefix in dial peer to have call pick up
function.
13
