5. Appendix
5.1. Specification
5.1.1. Device specification
Item this VoIP Phone
Adapter(Input/Output)
Input：100-240VAC 50-60Hz Output：DC 5V/1A
Port
WAN 10/100Base- T RJ-45 for LAN
LAN 10/100Base- T RJ-45 for PC
Power Consumption
Idle：1.5W/Active：1.8W
LCD size
74 x 28mm dot-matrix LCD
Operation
Temperature
0～40℃
Relative Humidity
10～65%
Main Chipset BCM 1190
SDRAM 16Mbits
Flash 4Mbits
Size（W x H x D）
11.6×8×3 in.(295×205×75mm)
Weight 2.07lb.(0.94kg)
5.1.2. Voice Features
Support 2 lines SIP, SIP 2.0 (RFC3261)
Codec：G.711A/u，G.723 high/low, G.729
Echo cancellation ： Support G.168 and hand-free can support 96ms
Support VAD，CNG
NAT transverse: support STUN
Supports full duplex.
SIP support SIP domain，SIP authentication（none，basic ， MD5），DNS name of server,
peer to peer
SIP support 2 SIP lines. Can connect to SIP1 and SIP2 server at the same time
DTMF：SIP info，DTMF Relay，RFC2833
SIP application: support Call forward/ transfer/ holding/ waiting / 3 way talking/ paging and
intercom/pickup/join call/redial/unredial/push to talk/click to dial/call park
Call control features: Flexible dial map, support hotline, empty calling no. reject server, black
list for reject, authenticated call, no disturb, caller ID and so on.
Support phonebook 500 records, incoming calls / outgoing calls / missing calls. Each supports
100 records
support conference call and record on server
Could dial use private server automatically when public server unregistered while private
server is resgistered successfully
Phonebook supports VCard standard
Support 12/24 time format.
12/24 hours time display
Support daylight saving time
Support path, gruu
Support SIP Privacy.
Support 9 kind of ring type
5.1.3. Network Features
WAN/LAN: support Bridge and Router mode.
Support basic NAT and NAPT
Support PPPoE for xDSL
52
