WAN Config
Field Name explanation
Active IP The current IP address of the phone.
Current Netmask The current Netmask address.
MAC Address The current MAC address of the phone.
Current Gateway The current Gateway IP address.
Get MAC Time Shows the time of getting MAC address
Please select the proper network mode according to the network condition. DPH-150S provide
three different network settings:
Static: If your ISP server provides you the static IP address, please select this mode, then
finish Static Mode setting. If you don’t know about parameters of Static Mode setting, please
ask your ISP for them.
DHCP: In this mode, you will get the information from the DHCP server automatically; need
not to input this information artificially.
PPPoE: In this mode, your must input your ADSL account and password.
You can also refer to 2.2. Initial Setting to speed setting your network.
Obtain DNS server
automatically
Using the DHCP mode to get the DNS address. If disable, it will using
the DNS address in the Static mode, the default is enable.
If you use static mode, you need set it.
IP Address Input the IP address distributed to you.
Netmask Input the Netmask distributed to you.
Gateway Input the Gateway address distributed to you.
DNS Domain
Set DNS domain postfix. When the domain which you inputted can not
be parsed, phone will automatically add this domain to the end of the
domain which you inputted before and parse it again.
Primary DNS Input your primary DNS server address.
Alter DNS Input your standby DNS server address.
If you uses PPPoE mode you need to make the above setting.
PPPoE Server It will be provided by ISP.
Username Input your ADSL account.
20
