D-Link DPH-150SE [35/53] Call service
![D-Link DPH-150SE [35/53] Call service](/views2/1013396/page35/bg23.png)
DSP Configuration
Field name explanation
First Codec The fist preferential DSP codec: G.711A/u, G.723, G.729
Second Codec The second preferential DSP codec: G.711A/u, G.723, G.729
Third Codec The third preferential DSP codec: G.711A/u, G.723, G.729
Forth Codec The forth preferential DSP codec: G.711A/u, G.723, G.729
Fifth Codec The fifth preferential DSP codec: G.711A/u, G.723, G.729
Input Volume Specify Input (MIC) Volume grade.
Handfree Volume Specify Handfree Volume grade
G729 Payload Length Set G729 Payload Length
Handdown Time Specify the least reflection time of Handdown, the default is 200ms.
Output Volume Specify Output (receiver) Volume grade.
Ring Volume Specify Ring Volume grade
G722 Timestamps 160/20ms or 320/20ms is available
G723 Bit Rate 5.3kb/s or 6.3kb/s is available
Default Ring Type Set up the ring by default
Signal Standard Select Signal Standard.
VAD Select it or not to enable or disable VAD. If enable VAD, G729 Payload
length could not be set over 20ms.
Dtmf Payload Type Set the payload type of DTMF 2833, the default is 101.
4.3.4.2. Call Service
In this web page, you can configure Hotline, Call Transfer, Call Waiting, 3 Ways Call, Black List,
white list Limit List and so on.
Call Service
Field name explanation
35
