4.3.5. Maintenance
4.3.5.1. Auto Provision
Auto Provision
Field name explanation
Current Config
Version
Show the current config file’s version.
Server Address Set FTP/TFTP/HTTP server IP address for auto update. The address
can be IP address or Domain name with subdirectory.
Username Set FTP server Username. System will use anonymous if username
keep blank.
Password Set FTP server Password.
Config File Name Set configuration file’s name which need to update. System will use
MAC as config file name if config file name keep blank. For example,
000102030405.。
Config Encrypt Key Input the Encrypt Key, if the configuration file is encrypted.
Protocol Type Select the Protocol type FTP、TFTP or HTTP.
39
