Step 4: push the on/off switch on the back of the phone to the on side, then the phone’s LCD
screen displays “Initializing…Wait LogOn…”. Later, a ready screen typically displays the greeting
word and the date, time and softkey name.
If your LCD screen displays different information from the above, you need refer to the next section
“Initial setting” to set your network online mode.
If your VoIP phone registers into corporate IP telephony Server, your phone is ready to use.
2.2. Initial Setting
This VoIP Phone provides you with rich function and parameters setting. If you have enough
knowledge about network and SIP protocol, it is better for you to understand many parameters. But
if you know little about network and SIP protocol, you can also easily make initial setting according
to the following steps to enjoy rapidly high quality voice and low cost from this VoIP Phone.
Before make initial setting, please check if your corporate IP telephony network can work normally,
and you have finished “connect the phone”.
This VoIP Phone Supports DHCP by default. It will receive an IP address and other network-
related settings (Netmask, IP gateway, DNS server) from the DHCP server. If your network
supports DHCP, you can connect this VoIP Phone directly to the network. If your network doesn’t
support DHCP, you need change this VoIP Phone’s network connection setting. According to the
following steps, change this VoIP Phone’s DHCP network connection setting into PPPoE or static
IP which your network supports at present.
2.2.1. PPPoE mode
1. Please prepare your PPPoE account name and password
2. Press the MENU key, and press the key for twice, the LCD screen will display “3
Network”. Then press the Soft2(Enter) key, the LCD screen will display “1 WAN”.
3. Press the Soft2(Enter) key, and press the key for twice, the LCD screen will display “3
PPPoE Set”.
4. Press the Soft2(Enter) key, the LCD screen will display “1 Account”, then press the Soft2(Enter)
key, there will display the account information; Press the Soft2(Edit) key and press the Soft1(Del)
key to delete and input your PPPOE account number then press the Soft2(Save) key to confirm.
With “Saved” displayed, screen will jump to show the account information currently.
5. Press the Soft3(Quit) key to return to the previous menu, then press the key, the LCD
screen will display “2 Password”.Then press the Soft2(Enter) key, there will display the
password information (it will replaced by *). Press the Soft2(Edit) key and press the Soft1(Del)
key to delete and input your PPPoE’s password and confirm it by the Soft2(Save) key, With
“Saved” displayed, screen will jump to show the password information currently(it will replaced
by *).
6. Press the Soft3(Quit) key for twice and press the key, the LCD screen will display “1 Net
Mode”. Press the Soft2(Enter) key and then press the soft2(Edit) key, you can choose the
network mode what you want by the navigation key. Now please choose the PPPoE mode by the
key, the LCD screen will display “<>PPPoE”, With Soft2(Save) pressed again,screen
will show “Saved” and then jump to show the net mode currently.
7. pressing Soft3 (Quit) four times/MENU key/Release key to quit to stand-by status and pressing
to shows “PPPoE”,phone tries to connect server to get IP. If there is shown
“Negotiating…”, it shows that the phone is trying to access the PPPoE Server, else it shows that
the phone has already get IP with PPPoE.
7
