D-Link DPH-150SE [37/53] Digital map configuration

3). Time Out: After you stop dialing and waiting time out, system will send the number collected.

4). User defined: you can customize digital map rules to make dialing more flexible. It is realized by

defining the prefix of phone number and number length of dialing.

In order to keep some users' secondary dialing manner when dialing the external line with pbx,

phone can be added a special rule to realize it. so user can dial a number as external line prefix

and get the secondary dial tone to keep dial the external number. after finishing dialing, phone will

send the prefix and external number totaly to ther server.

for example, there is a rule 9,xxxxxxxx in the digital map table. after dialing 9, phone will send the

secondary dial tone, user may keep going dialing. after finished, phone will call the number which

starts with 9, actually the number sent out is 9-digit with 9.

Digital Map Configuration

Field name explanation

End with "#" Set Enable/Disable the phone ended with “#” dial.

Fixed Length Specify the Fixed Length of phone ending with.

Time out Set the timeout of the last dial digit. The call will be sent after timeout.

Below is user-defined digital map rule:

[] Specifies a range that will match digit. May be a range, a list of ranges separated by commas,

or a list of digits.

x Match any single digit that is dialed.

. Match any arbitrary number of digits including none.

Tn Indicates an additional time out period before digits are sent of n seconds in length. n is

mandatory and can have a value of 0 to 9 seconds. Tn must be the last 2 characters of a dial

plan. If Tn is not specified it is assumed to be T0 by default on all dial plans.
