VPN Configuration
Field name explanation
VPN IP Shows the current VPN IP address
Enable VPN Select it or not to enable or disable VPN；
VPN Server Addr Set VPN L2TP Server IP address
VPN User Name Set User Name access to VPN L2TP Server
VPN Password Set Password access to VPN L2TP Server
4.3.7. Logout
Click Logout，and you will exit web page. If you want to enter it next time, you need input user
name and password again.
50
