support VLAN
Support NAT penetration, and Stun penetration
Support DMZ
Support VPN( L2TP)
Support DHCP get IP on WAN port
Support DHCP distribute IP on LAN port
Qos supports Diffserv.
support network tools: contain ping，trace route，telnet client
5.1.4. Maintenance and Management
The phone supports post mode, can update firmware by post mode.
Supports different levels of administration.
Support Boot Monitor
Can upgrade firmware through boot monitor
access with different authority
support auto provisioning(upgrade firmware or configuration file)
Can config through Web, Keypad, Telnet
Can upgrade firmware and configuration file through HTTP, FTP, TFTP
Support syslog
5.2. Digit-character map table
Button Character Button Character
1 @ 7 P Q R S p q r s
2 A B C a b c 8 T U V t u v
3 D E F d e f
9 W X Y Z w x y
z
4 G H I g h i .
5 J K L j k l 0
6 M N O m n o #
53
