address”to send SMS.
Browse Message and reply message
When there’s new message, phone will ring and remind by a small envelope on top of the
screen, then press soft1 (SMS), and Soft2(Enter) key to browse current new message. when
there are more new messages come in, user can choose by using up and down keys, then press
Soft2(Enter) key to check the sender’s number and message content, next, press Soft2(Reply)key
and input message content, finally, press Soft2(Send) again to reply this message.
Note: while user browses the message numbers, new messages will be marked by “new”; when
user edits message, press # key that to switch input method, e.g. ABC (uppercase English input),
abc (lowercase English input), 123(digit input), Korean (Korean input(if your phone’s firmware
version supports Korean). PY,( if your phone’s firmware version supports Chinese)
3.2.2. Memo function
Press soft3 ( Memo) key in standby, then Soft1(ADD) key, at this time, user can configure the
future date time in terms of Time format, next, press down key to input the memo content, also can
press # to switch input method, down key again to enter into reminder ring tone and down key at
the third time to enter into ring mode. You can press right or left key to select your reminder ring
tone after you enter into reminder ring tone, and select your ring mode by pressing right or left key
after entering into ring mode. There are two ring modes, ring and text. Ring is reminder you by ring
tone, text only show memo content without ring tone reminder. Finally, press soft2( save) key to
save your memo.
Note: if there is memo notice when your phone is in call/off-hook/hands-free status, phone does
not reminder by ring tone, only shows memo content in screen.
3.2.3. SpeedDial function
User can pre-defined numbers in these keys(numeric key 0-9). Hook off, press the defined
numeric key, then input “#”. Your pre-defined numbers will send out.
3.2.4. Realize Secondary Dial by Dialing for only one time
When you make secondary dial in off-hook/hands-free or standby pre-input mode, press
button to postpone input, and screen display will show ^. one stands for 2 seconds. For
example, you input 123^45, the phone will send DTMF( 45) 2 seconds after the phone call 123.
123^^^45 will make phone send DTMF(45) at 6 seconds interval
3.2.5. Phonebook prefix function
At standby mode, press phonebook button, user can not only select his needed number to
call out but also he can add prefix to numbers, then call out. It is convenient for user add prefix
numbers that PBX need.
3.2.6. Function key
If function key is set as SIP Line key, user can select which lines will be used to make call when
dialing or make a 2nd dialing by this function key. Note that only the key which is registered is
available to be select to call.
This function key can be configured as “Key Event”, namely set as F_MWI. It can set relative keys
as Voice mail key, can check new and old voice mail; also can be set other function keys like the
following table:
Field Name Explanation
F_PBOOK Like the phonebook key.
F_REDIAL Like the redial key.
F_A_TRANSFER or
F_B_TRANSFER
Like the transfer key.
F_PICKUP Pickup function
F_JOIN Joincall function.
F_AUTOREDIAL Auto redial function.
12
