NAT Configuration
Field name explanation
IPSec ALG It is an encryption technology. Select it to enable IPSec ALG, the default
is enable
FTP ALG
FTP is a service of connection layer which can transform intranet IP into
extranet IP when intranet IP is sending out packet.
Select it to enable FTP ALG, the default is enable
PPTP ALG Select it enable PPTP ALG, the default is enable
Shows the NAT TCP mapping table
Shows the NAT UDP mapping table
48
