2.2.2. Static IP mode
1. Prepare the network’s parameters first. IP Address,Netmask , Default Gateway and DNS
server IP address are needed. Please contact the service provider or technician of network.
2. Pressing MENU key,and key for twice,screen shows“3 Network”, then pressing
Soft2(Enter),screen will show “1 WAN”.
3. Pressing Soft2 (Enter),then pressing key, screen shows“2 Static Set”.
4. Pressing Soft2(Enter) to make screen show“1 IP”,press Soft2(Enter) and then press
Soft2(Edit) again, and Soft1(Del) to delete old parameter. Input your IP address and press Soft2
(Save). After “Saved” shown, screen will jump to show the IP information currently.
5. Press key to show “2 Netmask”. Press Soft2(Enter) and press Soft2(Edit) again,and
then use Soft1(Del) to delete. Input your Netmask and press Soft2 (Save). After “Saved” shown,
screen will jump to show the Netmask information currently.
6. Press key to show “3 Gateway”. Press Soft2(Enter) and press Soft2(Edit) again,and
then use Soft1(Del)to delete,Input your gateway and press Soft2(Save). After “Saved” shown,
screen will jump to show the gateway information currentlly.
7. Press key to show“4 DNS”. Press Soft2(Enter) and press Soft2(Edit) again,and use
Soft1(Del) to delete. Input your DNS server address and press Soft2 (Save). After “Saved”
shown, screen will jump to show DNS information.
8. Press twice Soft3 (Quit) quitting. With key pressed,screen shows“1 Net Mode”. Press
Soft2(Enter) and press Soft2(Edit) again, and key,screen shows“<>Static”; with
Soft2(Save) pressed,screen shows “Saved” and then shows the net mode currently.
9. pressing Soft3 (Quit) four times/MENU key/Release key to quit to stand-by status and pressing
to show “Static”. If screen shows the IP address and gateway which are set just now, it
shows that Static IP mode is taken effect.
2.2.3. DHCP mode
1. Press the MENU key, and press the key for twice, the LCD screen will display “3
Network”. Then press the Soft2(Enter) key, the LCD screen will display “1 WAN”.
2. Press Soft2 (Enter) to show “1 Net Mode”. After pressing Soft(Enter) and Soft2(Edit),using
navigation
key to select until screen shows “<>DHCP”. Press Soft2(Save),With “saved” displayed, screen
will jump to show the net mode currently.
3. Press Soft3 (Quit) four times quitting to stand-by status. Press key to show “DHCP”,if
there is “Negotiating…”shown on screen, it shows that phone is keep trying to search DHCP
server or get IP; If there is IP address displayed, it shows that DHCP mode has been taken
effect.
3. Basic Functions
3.1. Basic operation
3.1.1. Accepting a call
DPH-150S will ring to indicate you when there is call incoming,below is ways to answer call:
Pick up handset to accept incoming calls.
8
