3.1.7. Switchboard Operator feature
User can press Soft1 (Conf) to dial the line2(press Soft1(Answer) to answer the call directly
if this call is from line2) during talking with line1. After line2 connect, user can press Soft1 (Switch)
to select which line you prefer to transfer, then press to input the number you want to
transfer and press again to do the transfer.
3.1.8. Call records
DPH-150S supports 100 items of missed call, 100 items of incoming call, and 100 items of
outgoing call. If the records are full, the newest will replace the oldest. If phone’s power cut or
reboot, call records will be discarded.
Missed call
Press , and screen displays “Missed Call”. Press Soft2 (Enter), phone will show the
number and time of missed call. User can also use to browse the missed call records,
or press Soft2 (Detail) to check the details of this record, then press Soft2 (Dial) again to change
the current number. Pressing Soft2(Dial) will call this number directly if user don’t modify the
number. If there is no missed call, screen will show “List Is Empty”.
Incoming call
Press and switch the menu to “Incoming Call” by pressing . Press Soft2
(Enter), phone will show the number of incoming call. User can also use to browse
the incoming call records; or press Soft2 (Detail) to check the details of this record, then press
Soft2 (Dial) again to change the current number. Pressing Soft2 (Dial) will call this number directly
if user don’t modify the number. If there is no incoming call,screen will show “List Is Empty”.
Outgoing call
Press , and use to select to “Outgoing Call”. Press Soft2 (Enter), phone will
show the number and time of dialed call. User can also use to browse the dialed call
records; or press Soft2 (Detail) to check the details of this record, then press Soft2 (Dial) again to
change the current number. Pressing Soft2 (Dial) will call this number directly if user don’t modify
the number. If there is no dialed call, screen will show “List Is Empty”. User can also press to
check “Outgoing Call”.
3.2. The high-level operation
This VoIP Phone provides more advanced functions after setting at the permission scope of
SIP server.
3.2.1. SMS function
Send message
The followings list several methods to send message:
1.Press soft1(SMS) in standby, then press Soft1(new) key. After inputting SMS content, press
Soft2(send)key to input callee’s number, next, press Soft2 again to send SMS.
2. Press soft1(SMS) in standby, then press soft1(new) key. After inputting SMS content, press
soft2(send) key, then pbook key to select your number to send SMS.
3. After inputting SMS content, user can press soft2(send) key, then input “ #” and “the callee’s IP
11
