SIP Config
Field name explanation
Choose line to set info about SIP, there are 2 lines to choose. You can switch by 【Load 】 button.
Register Status Shows if the phone has been registered the SIP server or not; or so,
show Unapplied;
Server Name Set the server name.
Server Address Input your SIP server address.
Server Port Set your SIP server port.
Account Name Input your SIP register account name.
Password Input your SIP register password.
Phone Number Input the phone number assigned by your VoIP service provider.
Phone will not register if there is no phone number configured.
Display Name Set the display name.
Proxy Server Address
Set proxy server IP address（Usually, Register SIP Server
configuration is the same as Proxy SIP Server. But if your VoIP service
provider give different configurations between Register SIP Server and
Proxy SIP Server, you need make different settings.）
Proxy Server Port Set your Proxy SIP server port.
Proxy Username Input your Proxy SIP server account.
Proxy Password Input your Proxy SIP server password.
Domain Realm
Set the sip domain if needed, otherwise this VoIP phone will use the
Register server address as sip domain automatically. (Usually it is
same with registered server and proxy server IP address).
Enable Register Start to register or not by selecting it or not.
Register Expire Time
Set expire time of SIP server register, default is 60 seconds. If the
register time of the server requested is longer or shorter than the
expire time set, the phone will change automatically the time into the
time recommended by the server, and register again.
NAT Keep Alive Interval Set examining interval of the server, default is 60 seconds
User Agent Set the user agent if have, the default is VoIP Phone 1.0
Signal Key Set the key for signal encryption
Media Key Set the key for RTP encryption
Local port Set sip port of each line
Ring type Set ring type of each line
Hot line Number Set Hot line number of each line.
Transfer Expire Time The phone send bye and end the call as soon as hang up.
Enable Subscribe Enable Subscribe.
Enable Keep
Authentication
Enable/Disable Keep Authentication.
NAT Keep Alive
Enable/Disable keeps NAT of SIP alive.
If some server refuse to register with too short interval time, and has
no packets sending to device in private network to keep NAT alive,
user could set this function ON. It need set the keep alive interval time
less than the NAT server’s.
Enable Via rport Enable/Disable system to support RFC3581. Via rport is special way
to realize SIP NAT.
Enable PRACK Enable or disable SIP PRACK function, suggest use the default config.
Long Contact Set more parameters in contact field; connection with SEM server
Enable URI Convert Convert # to %23 when send the URI.
Dial Without Register Set call out by proxy without registration;
Ban Anonymous Call Set to ban Anonymous Call;
Select call forward mode, the default is Off
28
