Please select the proper network mode according to the network condition. DPH-150S provide
three different network settings:
Static: If your ISP server provides you the static IP address, please select this mode, then
finish Static Mode setting. If you don’t know about parameters of Static Mode setting, please
ask your ISP for them.
DHCP: In this mode, you will get the information from the DHCP server automatically; need
not to input this information artificially.
PPPoE: In this mode, your must input your ADSL account and password.
You can also refer to 2.2. Initial Setting to speed setting your network.
Choose Static IP MODE，click【NEXT】can config the network and SIP(default SIP1)easily, also
can browse them too. Click【BACK】can return to the last page.
Static IP Address Input the IP address distributed to you.
Netmask Input the Netmask distributed to you.
Gateway Input the Gateway address distributed to you.
DNS Domain Set DNS domain postfix. When the domain which you inputted can not
be parsed, phone will automatically add this domain to the end of the
domain which you inputted before and parse it again.
Primary DNS Input your primary DNS server address.
Alter DNS Input your standby DNS server address.
Display Name If user set the display name, callee will show this display name.
Server Address Input your SIP server address.
Server Port Set your SIP server port.
User Name Input your SIP register account name.
Password Input your SIP register password.
Phone Number Input the phone number assigned by your VOIP service provider.
Enable Register Start to register or not by selecting it or not.
17
