You can refer to the following examples of different alias application to know more how to use

different aliases and this dial rule.

Call Mode Select differenct signal protocol, SIP

Suffix Set suffix, this is optional config item. It will show no suffix if you don’t

set it.

Delete Length Set delete length. This is optional config item. For example: if the

delete length is 3, the phone will delete the first 3 digits then send out

the rest digits. You can refer to examples of different alias application to

know how to set delete length.

Introduction of how to set up dial-peer to implement switch between multi- SIP lines

9T mapping: If you have registered a SIP1 server and set dial-peer according to the above

table，all calls will be sent via SIP1 server when you press the numeric key “9” in front of dialing

destination phone numbers.

8T mapping: If you have registered a Private SIP2 server and set dial-peer according to the

above table，all calls will be sent via SIP2 server when you press the numeric key “8” in front of

dialing destination phone numbers.

Examples of different alias application

Set by web explanation example

You need set phone number,

Destination, Alias and Delete

Length.

Phone number is XXXT,

Destination is

255.255.255.255 and Alias is

del.

This means any phone No.

that starts with your set

phone number will be sent

via SIP2 line after the first

several digits of your dialed

phone number are deleted

according to delete length.

If you dial “93333”, the SIP2

server will receive “3333”

This setting will realize speed

dial function, after you dialing

the numeric key “2”, the

number after all will be sent

out.

When you dial “2”, the SIP1

server will receive 33334444
