AWK-6222 User’s Manual Introduction

1-8

Digital Inputs and Relay-out Pin Assignment (8-pin M12 connector)

PIN 1 2 3 4 5 6 7 8

Function DOUT_I DOUT_O DI0+ DI0- DI1+ DI1- reserved reserved
