AWK-6222 User’s Manual Support Information
7-2
About This User’s Manual
This manual is mainly written for, but not limited to, the following hardware and firmware for the
AWK-6222:
y Hardware Rev: 1.0
y Firmware Ver: 1.1
You are strongly recommended to visit Moxa’s website (http://www.moxa.com) and find the latest
pr
o
duct datasheet, firmware, QIG (Quick Installation Guide), UM (User’s Manual) and related
information.
NOTE
You can find out the hardware revision number of AWK-6222 on the back label.
The firmware version number can be seen on the Overview page, as follow:
