AWK-6222 User’s Manual Other Console Configurations

3-55

Save Configuration

The following figure shows how the AWK-6222 stores the setting changes into volatile and

non-volatile memory. All data stored in volatile memory will disappear when the AWK-6222 is

shutdown or rebooted unless they are saved. Because the AWK-6222 starts up and initializes with

the settings stored in flash memory, all new changes must be saved to flash memory before

restarting the AWK-6222.

This also means the new changes will not work unless you run either the Save Configuration

function or the Restart function.

After you click on Save Configuration in the left menu box, the following screen will appear.

Click Save if you wish to update the configuration settings in the flash memory at this time.

Alternatively, you may choose to run other functions and put off saving the configuration until

later. However, the new setting changes will remain in the non-volatile memory until you save the

configurations.

Restart

If you submitted configuration changes, you will find a blinking string in the upper right corner of

the screen. After making all your changes, click the Restart function in the left menu box. One of

two different screens will appear.

If you made changes recently but did not save, you will be given two options. Clicking the Restart

button here will reboot the AWK-6222 directly, and all setting changes will be ignored. Clicking

the Save and Restart button will apply all setting changes and then reboot the AWK-6222.
