AWK-6222 User’s Manual Introduction
1-5
* Please check Moxa’s website for the most up-to-date certification status.
Warranty
5 years
Details: See http://www.moxa.com/warranty
ATTENTION
The AWK-6222 is NOT a portable mobile device and should be located at least 20cm away from
the human body. The AWK-6222 is NOT designed for the general consumer. A well-trained
technician is required to safely deploy AWK-6222s and establish a wireless network.
.
Functions
LED Indicators
The LEDs on the front panel of AWK-6222 allow you to quickly identity the wireless status and
settings.
The FAULT LED will light upon system failure or user-configured events. If the AWK-6222
cannot retrieve the IP address from a DHCP server, the FAULT LED will blink at one second
intervals.
The following table is a summary of the wireless settings and LED displays. You can check the
status of the AWK-6222 by reading these LEDs. More information about “Basic Wireless
Settings” is presented in Chapter 3.
LED Color State Description
On
Power is being supplied (from power input 1 or 2, or
PoE)
PWR
Green
Off Power is not being supplied.
On Relay is event-triggered.
Blink (slow)
Cannot get an IP address from the DHCP server
(interval: 1 sec).
Blink (fast) IP address conflict (interval: 0.5 sec).
FAULT
Red
Off Normal status.
Green Software Ready.
Green Blink
The AWK Search Utility has located the AWK.
(interval: 1sec).
STATE
Green/Red
Red Booting or Error condition.
Green On WLAN is functioning in Client/Slave mode.
Green Blink WLAN’s is transmitting data in Client/Slave mode.
Amber On WLAN is functioning in AP/Bridge/Master mode.
Amber Blink
WLAN’s is transmitting data in AP/Bridge/Master
mode.
WLAN 1
Green/Amber
Off WLAN is not in use or not working properly.
Green On WLAN is functioning in Client/Slave mode.
WLAN 2
Green/Amber
Green Blink WLAN’s is transmitting data in Client/Slave mode.
