AWK-6222 User’s Manual Other Console Configurations
3-42
System Log
System Log Event Types
Detailed information for grouped events is shown in the following table. You can check the
Enable log box to enable event groups. By default all the values are enabled (checked). The log
for system events can be seen in Status Æ System Log.
System-related events Event triggers when…
System restart (warm start)
The AWK-6222 is rebooted, such as when its settings
are changed (IP address, subnet mask, etc.).
Network-related events Event triggers when…
LAN 1 or LAN 2 link on The LAN port is connected to a device or network.
LAN 1 or LAN 2 link off
The port is disconnected (e.g., the cable is pulled out,
or the opposing device shuts down).
Client joined/ left for WLAN 1 or
WLAN 2
(for Redundant AP, AP, or
Master mode)
A wireless client is associated or disassociated.
WLAN 1 or WLAN 2 connected
to AP
(for Redundant Client, Client,
or Slave mode)
The AWK-6222 is associated with an AP.
WLAN 1 or WLAN 2
disconnected
(for Redundant Client, Client,
or Slave mode)
The AWK-6222 is disassociated from an AP.
Config-related events Event triggers when…
Configuration Changed A configuration item has been changed.
Configuration file import via Web
Console
The configuration file is imported to the AWK-6222.
Console authentication failure An incorrect password is entered.
Firmware upgraded The AWK-6222’s firmware is updated.
Power events Event triggers when…
Power 1/2 transition (On Æ Off) The AWK-6222 is powered down in PWR1/2.
PoE transition (On Æ Off) The AWK-6222 is powered down in PoE.
Power 1/2 transition (Off Æ On) The AWK-6222 is powered via PWR1/2.
