AWK-6222 User’s Manual Other Console Configurations
3-14
AP functionality
Setting Description Factory Default
Disable
Redundant AP cannot serve
non-redundant Clients.
Enable
Redundant AP can serve
non-redundant Clients.
Disable
Wireless Bridge Mode’s Master
You are allowed to edit this AP functionality to Enable or Disable on the basic wireless settings
page. If AP functionality is set to Enable, the Status will appear as Active, which means that the
WLAN is ready to operate in the operation mode you are setting. For AP functionality settings,
click on Edit, as described below.
After Edit is selected, you can select Enable or Disable in AP functionality.
