AWK-6222 User’s Manual Other Console Configurations
3-48
SNMP Trap Receiver Settings
SNMP traps are defined in SMIv1 MIBs (SNMPv1) and SMIv2 MIBs (SNMPv2c). The two styles
are basically equivalent, and it is possible to convert between the two. You can set the parameters
for SNMP trap receivers through the web page.
1st / 2nd Trap version
Setting Description Factory Default
V1 SNMP trap defined in SNMPv1
V2 SNMP trap defined in SNMPv2
V1
1st / 2nd Trap server IP/name
Setting Description Factory Default
IP address or host name Enter the IP address or name of the trap
server used by your network.
None
1st / 2nd Trap community
Setting Description Factory Default
Max. 31 characters Use a community string match with a
maximum of 31 characters for
authentication.
alert
