AWK-6222 User’s Manual Other Console Configurations
3-31
You can import a new WLAN certificate in Import WLAN Certificate by following these steps:
1. Input the corresponding password (or key) in the Certificate private password field. Then
click Submit to set the password.
2. You can see the password displayed in the Certificate private password field. Then click on
the Browse button in Select certificate/key file and select the certificate file.
3. Click Upload Certificate File to import the certificate file. If it succeeds, you can see the
information uploaded in Current Certificate. If it fails, you may need to return to step 1 to set
the password correctly and then import the certificate file again.
NOTE
The WLAN certificate will remain after the AWK-6222 reboots. Even though it is expired, it can
still be seen on Current Certificate.
Advanced Settings
Several advanced functions are available to increase the functionality of your AWK-6222 and
wireless network system. The DHCP server helps you deploy wireless clients efficiently. Packet
filters provide security mechanisms, such as firewalls, in different network layers. Moreover, the
AWK-6222 can support the STP/RSTP protocols to increase reliability across the entire network.
In addition, SNMP support can ease the network management via SNMP protocols.
