AWK-6222 User’s Manual Other Console Configurations

3-12

AP-Client

AP-Client mode provides a more flexible topology to allow the user to configure the 2 RF modules

for an AP or Client.

Matching Table for AP-Client’s WLANs:

WLAN 1 WLAN 2 Allowable Settin

AP AP Allow

AP Client Allow

Client Client Not Allow

Client AP Allow
