AWK-6222 User’s Manual Other Console Configurations
3-27
Advanced Wireless Settings
Additional wireless-related parameters are presented in this section to help you set up your
wireless network in detail.
Transmission Rate
Setting Description Factory Default
Auto AWK-6222 will sense and adjust the data
rate automatically
Available rates User can manually select a target
transmission data rate
Auto
Transmission Power
Setting Description Factory Default
Auto
Specifies wireless signal coverage by
automatically selecting the strength of Tx
power
Full Equivalent to 100% of maximum Tx power
High Equivalent to 75% of maximum Tx power
Medium Equivalent to 50% of maximum Tx power
Low Equivalent to 25% of maximum Tx power
Full
Beacon Interval (for Redundant AP, AP, Master mode only)
Setting Description Factory Default
Beacon Interval
(40-1000 ms)
This value indicates the frequency interval
of the beacon
100 (ms)
