AWK-6222 User’s Manual Other Console Configurations
3-28
DTIM Interval (for Redundant AP, AP, Master mode only)
Setting Description Factory Default
Data Beacon Rate
(1-16384)
This value indicates how often the
AWK-6222 sends out a Delivery Traffic
Indication Message
1
Fragment threshold
Setting Description Factory Default
Fragment Length
(256-2346)
This parameter specifies the maximum size
a data packet before splitting and creating a
new packet
2346
RTS threshold
Setting Description Factory Default
RTS/CTS Threshold
(256-2346)
This setting determines how large a packet
can be before the Access Point coordinates
transmission and reception to ensure
efficient communication
2346
NOTE
You can refer to the related glossaries in Chapter 5 for more detailed information about the
above-mentioned settings. By setting these parameters properly, you can better tune the
performance of your wireless network.
Transmission distance
Setting Description Factory Default
Distance or max. range
for transmission
(500-11000m)
The distance specifies the transmission
distance or max. range between two AWK
devices. This parameter should be set
properly, especially for long-distance
communication.
500
Noise protection
Setting Description Factory Default
Enable/Disable The setting enhances the ability of the
AWK-6222 to filter wireless interference.
You should enable this option for
communication distances of under 500
meters and disable it for communication
distances of over 500 meters.
Enable
