AWK-6222 User’s Manual Other Console Configurations
3-38
NOTE
We recommend you set use the edge port setting for ports that are only connected to
non-STP/RSTP sub-networks or end devices (PLC, RTU, etc.) as opposed to network equipment.
This can prevent unnecessary waiting and negotiation of STP/RSTP protocol, and accelerate
system initialization. When an edge port receives BPDUs, it can still function as an STP/RSTP
port and start negotiation.
Setting an edge port is different from disabling STP/RSTP on a port. If you disable STP/RSTP, a
port will not deal with STP/RSTP BPDUs at all.
Port Status
Port Status indicates the current Spanning Tree status of this port. Use Forwarding for normal
transmission, or Blocking to block transmission.
SNMP Agent
The AWK-6222 supports SNMP V1/V2c/V3. SNMP V1 and SNMP V2c use a community string
match for authentication, which means that SNMP servers access all objects with read-only or
read/write permissions using the community string public/private (default value). SNMP V3,
which requires you to select an authentication level of MD5 or SHA, is the most secure protocol.
You can also enable data encryption to enhance data security.
The AWK-6222’s MIB can be found in the software CD and supports reading the attributes via
SNMP. (Only get method is supported.)
SNMP security modes and security levels supported by the AWK-6222 are shown in the following
table. Select the security mode and level that will be used to communicate between the SNMP
agent and manager.
