AWK-6222 User’s Manual Other Console Configurations
3-39
Protocol
Version
Setting on
UI web
page
Authentication
Type
Data
Encryption
Method
V1, V2c
Read
Community
Community
string
No
Use a community string match for
authentication
SNMP
V1, V2c
V1, V2c
Write/Read
Community
Community
string
No
Use a community string match for
authentication
No-Auth None No
Use admin or user account to
access objects
MD5 or
SHA
Authentication
based on MD5
or SHA
No
Provides authentication based on
HMAC-MD5, or HMAC-SHA
algorithms. 8-character passwords
are the minimum requirement for
authentication.
SNMP V3
MD5 or
SHA
Authentication
based on MD5
or SHA
Data
encryption
key
Provides authentication based on
HMAC-MD5 or HMAC-SHA
algorithms, and data encryption
key. 8-character passwords and a
data encryption key are the
minimum requirements for
authentication and encryption.
The following parameters can be configured on the SNMP Agent page. A more detailed
explanation of each parameter is given below the following figure.
