AWK-6222 User’s Manual Other Console Configurations
3-33
Primary/ Secondary DNS server
Setting Description Factory Default
IP address of Primary/
Secondary DNS server
The IP address of the DNS Server used
by your network. After entering the DNS
Server’s IP address, you can use URLs.
The Secondary DNS server will be used
if the Primary DNS server fails to
connect.
None
Start IP address
Setting Description Factory Default
IP address Indicates the starting IP address which
the AWK-6222 can assign.
None
Maximum number of users
Setting Description Factory Default
1 – 999 Specifies how many IP address can be
assigned continuously
None
Client lease time
Setting Description Factory Default
1 – 10 days The lease time for which an IP address is
assigned. The IP address may expire after
the lease time is reached.
10 (days)
Packet Filters
The AWK-6222 includes various filters for IP-based packets going through LAN and WLAN
interfaces. You can set these filters as a firewall to help enhance network security.
MAC Filter
The AWK-6222’s MAC filter is a policy-based filter that can allow or filter out IP-based packets
with specified MAC addresses. The AWK-6222 provides eight fields for filtered MAC addresses.
Remember to check the Active check box for each entity to activate the setting.
Enable
Setting Description Factory Default
Enable Enables MAC filter
Disable Disables MAC filter
Disable
